Drawing
Telaio > Forcella

Valid for:

Rif.	Sku	Name	Price	Qty needed
2	021.34.130.80.00	GAMBA DESTRA COMPLETA	548,29 €	1
3	021.34.110.80.00	GAMBA SX COMPLETA	505,90 €	1
4	021.34.007.00.00	TRAPEZIO SUPERIORE RR/MOTARD 4T LC	198,73 €	1
5	021.34.059.82.00	KIT PIASTRE FORCELLA	526,70 €	1
12	11.55510.000	BULLONE 8.40 RS CH	1,96 €	1
10	29.01922.000	TAPPO FORCELLA .08024	5,00 €	1
11	021.34.008.00.00	CAVALLOTTO FIS.MANUBRIO RR/MOT. 4T 125LC	13,66 €	1
14	021.34.031.80.00	TAPPO GAMBALE CMPL RR/MOTARD 4T LC	8,26 €	1
15	021.34.032.00.00	GAMBALE RR/MOTARD 4T LC	438,18 €	1
16	024.34.664.00.00	ANELLO D'ARRESTO	8,44 €	1
17	024.34.667.00.00	RONDELLA	20,30 €	1
18	10.41281.000	ANELLO DI TENUTA FORCELLA .08112/5/6/8	16,62 €	1
19	10.41478.000	ANELLO FERMA PARAOLIO15.08028/9	0,96 €	1
23	16.50510.000	GUARNIZIONE .15.1 IN RAME	0,56 €	1
25	021.34.020.00.00	TUBO D.41 DX CMPL RR/MOTARD 4T LC	206,49 €	1

To see all drawing, select a model
