Drawing
Telaio > Ruota Posteriore

Valid for:

Rif.	Sku	Name	Price	Qty needed
1	024.42.017.42.59	CERCHIO POSTERIORE	223,55 €	1
4	021.42.012.00.00	CORONA Z.56 MOTARD VEM125	100,59 €	1
5	024.42.001.00.00	DISCO FRENO POSTERIORE WAVE RR	55,03 €	1
7	31.30476.000	VITE TBCE 6.16	0,56 €	4
8	021.42.003.00.00	PERNO RUOTA POSTERIORE VEM125	32,11 €	1
9	021.42.002.00.00	DIST.RUOTA POST.DX(L/DISCO)VEM125 ENDURO	4,21 €	1
10	021.42.004.00.00	DIST.RUOTA POST.SX(L/CORON)VEM125 ENDURO	5,14 €	1
11	12.97005.000	CUSCINETTO .47.14 RS PER MOZZI	36,14 €	2
12	13.62727.000	DISTANZIALE INT. MOZZO POST. RR	15,73 €	1
13	27.71210.000	RONDELLA ,2 . . 3	2,54 €	1
14	13.29600.000	DADO .1,5	5,75 €	1
15	13.17031.000	DADO M8 AUTOBLOCCANTE CONELOCK	0,66 €	4
17	31.64030.000	VITE TBIB 8.30	2,33 €	4
18	021.42.017.00.00	CATENA 1/2.5/16 P-136	66,39 €	1
19	021.42.018.00.00	MAGLIA	10,16 €	1
20	021.42.022.00.59	RUOTA POSTERIORE BLACK RR 4T R LC	580,59 €	1
21	021.42.001.80.00	MOZZO POSTERIORE DIAMANTATO COMPL.	226,71 €	1
22	024.42.053.00.59	RAGGIO 3,5.186	1,20 €	36
24	23.10110.000	NIPPLES D.3,5	0,90 €	36
25	15.38202.000	FLAP .45	7,91 €	1
